— PCB ASSEMBLY
Prototype Assembly
HyperPCB assembles prototype quantities with no minimum order, free DFM and DFA review, and the same AOI, X-ray and test steps used in production — so bench results carry over to the volume build.
— SPECIFICATIONS
Capability & tolerance chart
| Parameter | Standard |
|---|---|
| Minimum Order Quantity | 1 piece |
| Review | Free DFM and assembly review before build |
| Inspection | 100% AOI; 3D X-ray on BGA and hidden joints |
| Sourcing | Turnkey, partial turnkey or consigned parts |
| Rework | BGA rework and component replacement in-house |
| Follow-On | Same process into 100 – 1,000 piece production |
A prototype worth trusting
Hand-built prototypes hide the problems that will appear at volume: paste release on fine-pitch pads, thermal shadowing near a heavy connector, tombstoning on asymmetric passives. Building the prototype with the production process makes those problems visible while they are still cheap.
What the assembly review covers
Pad and stencil geometry, courtyard clearances, polarity marking, panelisation and depanel stress, test point access and connector orientation — returned as a written list with recommendations.
— FAQ
Frequently asked questions
— RELATED
Related assembly services
Ready to build?
Upload your Gerber files for a free DFM review and a quote within 24 hours. Mutual NDA available.
